Teclock Dial Depth Gauge, 5mm/0.01 – DM-250 Series
Teclock DM-250 Series – Dial depth gauge with low measuring force for depth, steps work and coating thickness measurement by MSP Metrology (M) Sdn Bhd from Teclock Japan.
Features
Measure Features
Dial Depth Gauge can be used to measure depth and steps of work piece and coating thickness.
Low Measuring Force
Low measuring force type is also available, which seldom hurts work piece.
Full Specifications
| Model | Graduation (mm) | Measuring Range (mm) | Indication Error (μm) | Contact Point Form (mm) | Standard Contact Point | Measuring Force (N) | Weight (g) |
| DM-250 | 0.01 | 5 | ±10 | Needle | ZS-518 | 1.4 or less | 2305 |
